T09-6241 Black Large Spiked Frame Hinge

6241 Black Large Spiked Frame Hinge 24x38mm heavy duty 0.7mm thick structural panel hardware

Industrial machinery

Request a quote

Factory-direct pricing · EXW Yiwu

Available — confirm lead time with sales

Category: Picture Framing Hardware / Hinges
MOQ: 100
Lead time: 7-10days

Get quote

View range Contact us

Description

6241 Black Large Spiked Frame Hinge – Heavy-Duty Structural Frame Hardware

The 6241 Black Large Spiked Frame Hinge stands as the flagship of XKY Framing’s spiked hinge range. At 38mm tall and manufactured from 0.7mm cold-rolled steel, this hinge provides the bearing surface and spike penetration depth required for large-format picture frames, gallery canvases, and structural partition panels.

Heavy-Gauge Construction

The 0.7mm steel used in the 6241 is the thickest in the spiked hinge series, resisting deformation under dynamic loads such as wall vibration, shipping impacts, and repeated gallery rehang operations. At 6.7g per unit, it remains light relative to its impressive 24×38mm bearing area.

Specifications

Installation for Large Frames

Two 6241 hinges placed at equal thirds along the frame back provide optimal load distribution for frames up to 80cm on the longest side. For very large frames (over 100cm), four hinges are recommended. Drive with a wooden mallet; a rubber mallet may not generate sufficient force for the 0.7mm spike tabs.

Applications

Large oil canvas frames, oversized gallery prints, architectural panel joins, heavy display boards, mirror frames, and structural wall-mounted art installations.

Comparison Across the 62xx Series

The 6241 is the largest in the 62xx spiked series. For comparison: 6220 (T05) is 13×16mm at 1.4g; 6229 Black (T06) is 14×27mm at 1.9g; 6234 (T08) is 18×28mm at 2.9g; and the 6241 tops out at 24×38mm at 6.7g, offering the most coverage for demanding applications.

For technical load data, see structural load principles.

Specifications

SKU	T09
Product Type	hardware
MOQ	100
Lead Time	7-10days
Overview	<p>The 6241 Black Large Spiked Frame Hinge is the heaviest-duty hinge in the XKY spiked frame series. At 38mm tall, 24mm wide, and 0.7mm thick, it is designed for large picture frames, oversized canvas assemblies, and structural panel joins where lightweight hinges would be insufficient.</p>
Highlights	Heavy-duty 0.7mm steel
Custom Packaging	Yes
Overall Width	24mm
Overall Height	38mm
Hole Diameter	13mm
Upper Spike Span	Upper Spike Span
Spike Depth	6mm
Material Thickness	0.7mm
Weight	6.7g
Finish	Matte Black

Key specs
—	8

FAQ

How many 6241 hinges are needed for a large picture frame?

For frames up to 80cm on the long side, use two hinges at equal thirds. For frames 80–120cm, use three hinges. For frames over 120cm, use four hinges or contact XKY Framing for custom hardware advice.

Can the 6241 replace the 6229 in all applications?

The 6241 is over-engineered for small frames and its larger footprint may be visible on frames with narrow mouldings (under 20mm). Use the 6229 or 6234 for smaller formats.

Is the 6241 available in a silver or natural finish?

Currently only available in matte black. Silver and natural steel finishes are available as special order items; contact XKY Framing for details.
